2.54mm Pitch Female Header 5mm Base Dual Beam Folded Contact Double Row (Straight) (P950X-XX-XX)
Description
It’s dual beam folded contacts provide reliable conductivity, electronic applications requiring precise and durable interconnections.
Material and Finish
Insulation
Material: |
Polyester |
Flammability: |
UL94V-0 |
Color: |
Black |
Contact
Material: |
Copper Alloy |
Solder Tails: |
Refer Table |
Packaging Type: |
Tube/Tray |
Electrical Characteristics
Current Rating: |
1A |
Insulation Resistance: |
5000M OHMS Min |
Dielectric withstanding: |
500V AC/Min |
Contact Resistance: |
20m OHMS Max |
Mechanical Data
Insertion Force: |
200g max |
Extraction Force: |
20g min |
Part No
P950X-XX-XX
