1.0mm Pitch Pin Female Header Double Row (Straight) (P9443-XXX121)
Description
It is a compact and reliable connector designed for electronic circuits. It features two rows of pins, spaced 1.0mm apart, ideal for connecting printed circuit boards (PCBs).
Material and Finish
Insulation
Material: |
Thermoplastic |
Flammability: |
UL94V-0 |
Color: |
Black |
Color
Material: |
Copper Alloy |
Finish: |
Gold Plated |
Packaging Type: |
Standard |
Electrical Characteristics
Contact Rating: |
1A |
Insulation Resistance: |
1000M OHMS Min |
Dielectric withstanding: |
500V AC |
Contact Resistance: |
20m OHMS max |
Part No
P9443-XXX121
