Wafer Disconnectable, Surface Mount (Right Angle) (P9077R29-19-X)
Description
It is a compact, right-angle connector designed for board-to-wire connections with a 1.0mm pitch.
Specifications
No. of Ways |
2-20 |
|---|---|
Voltage Rating |
50V AC,DC |
Current Rating |
1A AC,DC |
Contact Resistance |
20mΩ max |
Insulation Resistance |
500MΩ min |
Temperature Range |
-25°C to +85°C |
Dielectric Withsatnding |
500V AC/Minute |
Crimp Terminal Wire Size |
28-32 AWG |
Insulation O.D |
0.80mm max |
Material & Finish
Crimp Contact |
Copper Alloy, Tin Plated |
|---|---|
Square Pin |
Copper Alloy, Tin Plated |
Insulator |
Nylon 6T, UL94V-0 |
Part No
P9077R29-19-X
