Ø2.50mm DC Power Jack (Locking Option), Right Angle (PDCJ01-08)
Description
The locking option ensures a stable and reliable connection, preventing accidental disconnections.
Material and Finish
No |
Part Name |
Material |
QTY |
Finishing |
1 |
Case |
PBT |
1 |
Black |
2 |
Plug Pin |
Brass |
1 |
Ni Plated |
3 |
Spring Terminal |
PBS Strip/Stainless Steel |
1 |
Ag Plated Over Ni Plated |
4 |
Terminal |
Brass Strip |
1 |
Ag Plated Over Ni Plated |
5 |
Contact |
Brass Strip |
1 |
Ag Plated Over Ni Plated |
6 |
Insert Case |
PBT |
1 |
Black |
Electrical Characteristics
Insulation Resistance: |
100M OHMS Min @ 500V DC for 1 minute |
Dielectric Strength: |
500V AC For 1 Min |
Contact Resistance: |
100m OHMS Max |
Current Rating: |
5A |
Voltage Rating: |
24V DC |
Mechanical Data
Insertion Force: |
1.50kgf TYP |
Extraction Force: |
0.30 – 2.0kgf |
Mating Cycles: |
1000 Cycles Min |
Part No
PDCJ01-08
