2.54mm Pitch Pin Header Double Row (Straight) (P9103-XX-XX-X)

Description

The P9103 is a double row, straight pin header with a 2.54mm pitch, designed for reliable and efficient electrical connections.

Specification

Pin Retention Force:
1Kg.Min

Material and Finish

Material:
Glass Filled Polyester
Flammability:
UL94V-0
Color:
Black

Electrical Characteristics

Current Rating:
5A
Insulation Resistance:
10000M OHMS Min
Dielectric withstanding:
2000V AC /Min

Part No

P9103-XX-XX-X
