FPC 0.5mm PITCH CONNECTORS VERTICAL TYPE TOP CONTACT (P7065V21-24XXAT)
Description
This connector is ideal for use in high-density circuit boards, offering excellent conductivity and durability.
Material and Finish
Insulation
Housing: |
LCP |
Flammability: |
UL94V-0 |
Crimp Terminal: |
Phosphor Bronze |
Electrical Characteristics
Current Rating: |
0.4A |
Insulation Resistance: |
500m OHMS |
Dielectric withstanding: |
200V AC/Min |
Contact Resistance: |
≤20 OHMS |
Voltage Rating: |
50V |
Environmental Data
Temperature Range: |
-20℃ TO +85℃ |
Part No
P7065V21-24XXAT
