USB 2.0-RECEPTABLE (P7070AS04-5)

Description

It is a vertical mount, top entry, straight connector designed for high-speed data transfer and power supply.

Temperature range : -40°C to +80°C

Material and finish:

Insulator : PBT, UL94V-0, white color

Pin material : Brass, selecetive gold plated (gold on mating side & tin on soldering side)

Shell: SPCC

Current rating : 1.5A

Contact resistance :30MΩ max

Insulation resistance: 100MΩ MIN

Dielectric withstanding: 750Vrms AC

P7070AS04-5
