2.0mm Pitch Male Connector, Dual Row SMT with Screw Locking, RoHS(P808SM-XX-1A)
- Description
- Material and Finish
- Electrical Characteristics
- Mechanical Data
- Environmental Data
- Part No
Description
Dual-row SMT design with screw locking for secure mounting, ensuring strong mechanical stability and reliable signal transmission in high-density PCB applications. RoHS compliant.
Material and Finish
Insulator Body: |
PPS (Polyphenylene Sulfide Fibreglass Filled Thermoplastic) |
Flammability: |
UL94V-0 |
Contact Area: |
Copper Alloy / Ni+Au Flash 0.1µ |
Contact Tail: |
Copper Alloy / Ni+Au Flash 0.1µ |
Fixing Hardware: |
Jackscrew (Stainless Steel) |
Electrical Characteristics
All Contacts: |
3A Max. @25°C2.2A Max. @85°C |
Working Voltage (Sea Level) |
Tested at 800V DC |
Proof Voltage |
Tested at 1200V DC |
Contact Resistance (Initially) |
10 mΩ Max |
Insulation Resistance |
1000 mΩ Max. |
Mechanical Data
Mechanical life cycle: |
500 Cycles Min. Up To 2500 |
Retention Force: |
0.2N min/contact |
Insertion force: |
2N max/contact |
Environmental Data
Temperature range: |
-60°C to +260°C |
Vibration: |
0.75mm, 10g RMS 5 hours long random with superimposed sinusoid. No intermittence measured when using an H.S.L.C. (high speed logic interrupt) detector with a trip threshold of 2 nsec. |
Shock severity: |
100g for 6 msec |
Humidity test: |
56 days @ 90% humidity |
Solvent resistance: |
HCFC 141 bMGX (Atochem) solvent |
Salt spray test: |
96 hours |
Part No
P808SM-XX-1A
