2K METAL CIRCULAR CONNECTOR, STRAIGHT PLUGS , ROHS (PMCP001-CM-5P-12)
Description
Durable straight plug connector with robust metal construction, engineered for secure and stable connections, offering reliable performance in demanding industrial environments with RoHS compliance.
Material and Finish
Insulation
Material: |
Thermoplastic |
Flammability: |
UL94V-0 |
Contact
Shell Assembly
Outer Shell: |
Aluminium Alloy, Cr Plating |
Other Metallic Components: |
Copper Alloy, Ni Plating |
Nut: |
Copper Alloy, Ni Plating |
Center Contact: |
Copper Alloy, Gold Plating |
O-Ring: |
Elastomer |
Pin Engagement Length |
3.9mm |
Number Of Contacts: |
5 Position |
Electrical Characteristics
Rated Current For Power Contact: |
15A |
Rated Current For Signal Contact: |
2A |
Insulation Resistance: |
2000MΩ Min |
Dielectric Strength: |
3.2~3.5 (At 10⁶ Hz) |
Environmental Data
Temperature Range: |
-55°C To +125°C |
Protection Class: |
IP68 (For Both Mating & Un-Mating Conditions) |
Part No
PMCP001-CM-5P-12
