2.0mm Pitch Male Connector 3 Row Right Angle, RoHS(P8093SM-XXX-1A)
- Description
- Material and Finish
- Electrical Characteristics
- Mechanical Data
- Environmental Data
- Part No
Description
3-row configuration with right-angle design for space-saving PCB layouts, ensuring secure mating and reliable signal transmission. RoHS compliant.
Material and Finish
Insulator body: |
PPS (polyphenylene sulfide, fiberglass filled thermoplastic) |
Flammability: |
UL94V-0 |
Outer shell: |
Copper alloy, nickel + 0.25µ gold plated |
Inner clip: |
BeCu 6 finger clip, nickel + 1.27µ gold plated |
Fixing Hardware
Guide pins: |
Stainless steel |
Electrical Characteristics
Contacts: |
3A max |
Test voltage: |
750V RMS, 60Hz @ sea level (EIA-364-20 method-A)
|
Contact resistance: |
0.015Ω max (interface measurement) @ 3A (EIA-364-06) |
Insulation resistance: |
5000MΩ min @ 500VDC (EIA-364-20) |
Mechanical Data
Pin insertion force: |
0.071 kg |
Mechanical life cycle: |
500 cycles min |
Environmental Data
Operating temperature: |
-65°C to +125°C |
Vibration severity: |
Mated connectors, test condition III (EIA-364-28) |
Shock severity: |
Mated connectors, test condition G (EIA-364-27) |
Solvent resistance: |
HFC 141 bMGX (Atochem) solvent |
Salt spray test: |
Mated connectors, test condition B (EIA-364-26) |
Humidity test: |
Mated connectors tested as per EIA-364-31, type II (except steps 7A and 7B) |
Thermal Shock : |
Tested to the temperature ectremes of EIA-364-32,Test Condition -A |
Sizes 50+: |
Upon engagement ,Center area of mating faces may remain open (0.254–0.635 mm) due to slight flexing of molding. Vibration or shock should provide complete closure |
Part No
P8093SM-XXX-1A
