2.54mm Pitch Female Header 5mm Base Dual Beam Folded Contact Single Row(Straight) P9501
Description
P9501
SPECIFICATION
| Current Rating | 1A |
|---|---|
| Contact Resistance | 20mΩ max |
| Insulation Resistance | 5000MΩ min |
| Dielectric Withstanding | 500V AC |
| Insertion Force/Contact | 200gms max |
| Extraction Force/Contact | 20gms min |
| Mechanical Life | 100 Cycles min |
| Temperature Range | -40°c to +105°c |
MATERIAL AND FINISH
| Contact | Copper Alloy |
|---|---|
| Insulator | Polyester, UL 94V-0 |
